The Qweremin

I invented a new instrument: The Qweremin is a qwerty theremin.

Background

In the summer of 2022 I built a C64-based theremin, described and explained here. The theremin, of course, is one of the oldest electronic instruments. Its main drawback—and strength—is that it's incredibly hard to master. The performer has ultimate control over volume and pitch, but it takes months of practice before you can play even a simple scale.

Meanwhile, I've also developed a line of instruments featuring qwerty keyboards, where the keys are laid out as on a Type B chromatic button accordion. The earliest example is the Sixtyforgan, presented in spring 2021, but there's also Qwertuoso, the Commodordion, the Paulimba, and the C=TAR. For these instruments, the main challenge has been how to incorporate phrasing and other forms of musical expression; to move beyond the rudimentary note-on, note-off of an organ.

The Qweremin represents the unification of these two worlds. On the one hand (pun intended) you have ultimate control over volume and expression, and on the other you can play quick melodies with large jumps, and even chords. It is my most expressive 8-bit instrument yet.

The volume control

As mentioned in the presentation video at the top of this page, the SID chip only offers a crude 4-bit master volume control. For greater precision you have to work with the envelope generators, but those always produce ADSR curves. What I did in the original theremin project was to hack together a feedback loop that would continuously monitor the current output level from one of the envelope generators: When the present level was lower than the desired volume, I would trigger a new note to enter the attack phase, and when the level was too high, I would release the note. In this way I could make the envelope generator hover around any desired volume.

To make this work, I had to set the attack and release rates carefully. Too fast, and the volume would audibly oscillate back and forth between two levels. Too slow, and the volume changes would lag far behind the hand movements. I thought I had found a sweet spot, but it turned out I was being naïve.

In 2023 I ran into Bass Cadet, a thereminist with a C64 background, at the Revision demo party. She had seen my video and was enthusiastic about some day being able to get her hands on (or near, technically speaking) a C64 theremin. It turned out that we were both planning to attend another party, X, later that year. And since I was going to bring my C64 anyway, it was a simple matter to throw the spoon and clamp into my luggage as well.

Now, I always knew that my homemade C64 theremin could never compete with the precision and responsiveness of a professional-grade instrument, but it was nevertheless very instructive to get feedback from a real thereminist. I learned that the biggest problem was the slow response of the volume control antenna; it wouldn't react to sudden changes, which made it impossible to control the phrasing or “shape” of individual notes.

Falling back on just using the master volume register made the instrument playable, but as expected you could hear the distinct levels. This is especially problematic towards the low end of the range: For instance, going from level 1 to level 2 doubles the amplitude of the sound, and that can be quite jarring in the middle of a pianissimo part.

So once I had the idea to make a Qweremin, I knew I had to pay more attention to the snappiness of the volume control. And since I was already relying on external components (the 555 timers), it wasn't a big deal to add an external DAC. Then I ran into the noise issue described in the presentation video, and added a second DAC chip to compensate for it. I'm aware that there are dual-channel DAC chips on the market; I used two separate chips because that's what I happened to have at home.

The C64 is still very much involved in the operation of the volume antenna. It needs to decode the pulses from the 555, convert that to a desired volume level, and pass it to the DAC chips over the user port.

A touch of celebrity

By sheer coincidence, in the same year that I brought my C64 theremin to X, the organizers had invited legendary game music composer Rob Hubbard as a guest of honour. I was waiting in the long line of people who wanted to exchange a few words with him when Mahoney, who happened to be standing nearby, had the excellent idea that I should ask Rob to sign the clamp of my C64 theremin—something he gladly did!

Posted Friday 29-Aug-2025 06:46
