Glyptodont performed on the... Qwertar?

My SID tune Glyptodont performed live on a new C64-based instrument.

Update 230726: It's called the C=TAR!

The C64 is running a modified version of Qwertuoso loaded from an autostart cartridge.

Introduction

Phrasing and dynamics are important in music, especially in the case of slow soulful melodies. In my ongoing adventure of converting Commodore 64 computers to musical instruments, I've tried to approach expression control in several different ways.

My Theremin offers precise control over pitch and volume, but the instrument is very difficult to play. The Commodordion uses a bellows for dynamics, but it's too heavy and unergonomical. For Monty on the 'Bin and Vocalise, I routed the SID audio through a simple volume knob next to the keyboard. This worked well in practice but was kind of unimaginative and visually underwhelming.

One thing I learned from the Commodordion project was that although the instrument was unwieldy on the whole, playing the right-hand-side keyboard—the one that remains stationary in front of the body—felt quite good. So with that in mind, I decided to build an instrument resembling a guitar. I went through a couple of iterations before settling on the final design. The first idea (which came to me in a dream, actually) was to have a little cart sliding on linear bearings along metal axles, and a rotary encoder to pick up the motion. The cart would have pushbuttons and a microcontroller on it, and the signals from the buttons and the encoder would be transmitted to the C64 electronically over the axles.

Distance meter

So I bought a couple of shafts and bearings and figured out a way to attach them to the C64. Three rods would be enough for power distribution and a simple serial communication protocol. But I couldn't find a good way to mount the rotary encoder while maintaining good friction against the rods. I eventually scrapped that idea and decided to use a distance meter instead of the encoder. A laser-based time-of-flight sensor would be able to measure the absolute distance between the cart and the C64, and would even be able do so from the other side—mounted on the C64 itself. This would simplify the communication, perhaps to the point where no microcontroller would be necessary.

I settled for a distance meter module called Pololu 4064 (but other makes should work just as well). It has a 500 mm range and operates autonomously. The module can run from 5 V, which is conveniently available on the C64 user port, and has a single digital output signal. As explained in the video, the distance meter works by measuring the time of flight of a laser pulse, but this event only lasts for a few nanoseconds and would be too fast for the C64 to observe directly. The output signal from the module is also a pulse with a width that is proportional to the distance, but the signal has been magnified (slowed down) a million times and is on the order of 1–2 ms. This translates to about 1000–2000 clock cycles on the C64.

We can put one of the CIA peripheral chips in the C64 in a special mode where it increments a timer only when one of the CNT inputs (on the user port) is high. The maximum resolution is half the C64 clock rate which gives us 500 distinct values, roughly one value per millimetre.

To synchronize the C64 application to the measurement cycle, we connect the output from the distance meter to CNT2 but also to the active-low FLAG2 interrupt pin. In this way we get a non-maskable interrupt just after each incoming pulse. When the interrupt arrives we can read the measurement value from the timer register and reset the timer in anticipation of the next measurement.

Touch sensors

Having come this far, I still had a vision of a sliding cart with buttons to control various functions. But I noticed that the half-finished instrument looked kind of cool with just the rods sticking out. Perhaps I could do away with the cart entirely, and measure the distance to my hand instead! But what about the buttons?

As explained in my Theremin video, when you move your hand near an electric conductor, its capacitance to ground increases very slightly. If you actually touch it, the change is even bigger. You can drive a piece of metal to some known voltage—let's say 0 V, ground level—and then charge it slowly through a resistor to a different voltage, such as 5 V. By measuring how long it takes for the metal to reach an arbitrary threshold level, let't say 2.5 V, you can estimate the capacitance—and this allows you to detect touch.

But the signals leading into the C64 are highly sensitive to electrostatic discharge (ESD), so it would be irresponsible to connect them directly to the metal rods. Instead, I designed a buffer circuit based on a quad op-amp chip (LMC660). This chip can run from a single 5 V power supply.

PB7 is configured as an output from the C64. It's connected to a voltage follower that drives its output to 0 V or 5 V, charging the rods through three large resistors. The remaining three op-amps are wired up as open-loop comparators. The voltage on each rod is compared to a fixed 2.5 V rail created from Gnd and 5 V using two 10 K resistors. The outputs from the comparators will be fully maxed out and close to 5 V or 0 V, so they resemble digital signals and can be sent back to the C64 through PB0–PB2.

The op-amp chip affords a certain amount of ESD protection, and even if it were to break down it would be easy to replace. If a voltage spike manages to get past the chip, it will be tamed by the 1 K resistors before reaching the C64.

Between measurements PB7 is held low for a long time, allowing the rods to reach ground level. To start a measurement cycle, PB7 is raised. A few clock cycles later, PB0–2 are sampled. If they've already reached a high level at this point, the capacitance was low, meaning the rod was floating. Otherwise, the capacitance was high and the rod was being touched.

It's important to always read the result a precise number of clock cycles after raising PB7. No interrupt or DMA should get in the way. It's easy to avoid DMA interference by checking the current raster position and delaying if a badline is about to happen, but what about the non-maskable interrupts repeatedly generated by the distance meter? The solution is to simply run the touch sensor code from within the distance-meter interrupt handler.

The code

Here's the C64 code for interfacing with the sensors. First we need to initialize the CIA timers and the interrupt vector:

        lda     #$7f    ; turn off all interrupts from CIA #2
        sta     $dd0d

        lda     #$ff    ; timer B will count down from $ffff
        sta     $dd06
        sta     $dd07

        lda     #$01    ; timer A will count down from 1 (in a loop)
        sta     $dd04
        lda     #$00
        sta     $dd05

        lda     #$00
        sta     $dd01   ; PB7 is initially low
        lda     #$80
        sta     $dd03   ; PB7 is output, the other bits are inputs

        lda     #$91    ; start timer A
        sta     $dd0e

        lda     #<nmi   ; set up non-maskable interrupt vector
        sta     $fffa
        lda     #>nmi
        sta     $fffb

        lda     #$90    ; enable FLAG interrupt
        sta     $dd0d

And here's the interrupt handler:

nmi
        sta     savea+1 ; save register A
        lda     $dd0d   ; acknowledge the interrupt

        ; handle the distance meter

        lda     $dd06   ; read timer (the register won't change now)
        sta     distlsb
        lda     $dd07
        sta     distmsb

        lda     #$79    ; restart timer B and configure it
        sta     $dd0f	; to count timer A overflows when CNT is high

        ; handle the touch sensors
waitdma
        lda     $d012   ; get raster Y position
        and     #$06
        cmp     #2      ; badline coming up? (assumes default screen mode)
        beq     waitdma ; yes, wait some more

        lda     #$80    ; charge rods (set PB7)
        sta     $dd01
        nop             ; wait a certain number of cycles before reading
        bit     0	; (you may have to adjust this based on e.g. rod size)
        lda     $dd01   ; read PB0, PB1, PB2
        and     #7
        eor     #7      ; rod is held if voltage is low, so let's invert the bits
        sta     heldrods

        lda     #$00    ; discharge rods (clear PB7)
        sta     $dd01
savea
        lda     #0      ; restore register A
        rti             ; return from interrupt

Naming the instrument

(Updated 230726)

As mentioned in the video, I had a hard time coming up with a good name for this instrument, so I reached out to the community for help.

After receiving several great suggestions, I finally settled on The C=TAR. Here's a brief video announcement of the new name.

Posted Friday 7-Jul-2023 10:51
